Ta'rif
So'rov yuborish
Asosiy ma'lumotlar
| Model raqami | 8SPP50 |
| Turi | Twist Ip |
| Material | PP |
| Tuzilishi | 3 Turing |
| Bobin uzunligi | 200 yoki 220 mtr / bobin |
| Rang | Moslashtirilgan |
| Birlashtirilgan ko'zlar | Moslashtirilgan |
| MOQ | Har bir rang uchun o'lcham uchun 1000kgs |
| Transport paketi | To'qilgan sumka |
| Spetsifikatsiya | 28-100mm |
| HS kodi | 56074900 |
| Ishlab chiqarish quvvati | 35, 000 Tonna/yil |
Ikki tomonlama bog'langan polyester arqonning parametri
| Dia | Circ | Og'irligi | 3-Trans | 8-Trans | 12-Trans | ||||||||
| mm | dyuym | dyuym | KG/M | KG/220M | ISO1140: 2012 (E) | Haqiqiy MBL/KN | Haqiqiy MBL/TON | ISO1140: 2012 (E) | Haqiqiy MBL/KN | Haqiqiy MBL/TON | ISO1140: 2012 (E) | Haqiqiy MBL/KN | Haqiqiy MBL/TON |
| MBL/KN | MBL/KN | MBL/KN | |||||||||||
| 10 | 3/8 | 1-1/4 | 0.08 | 16.94 | 14.40 | 18.00 | 1.84 | - | - | - | - | - | - |
| 12 | 1/2 | 1-1/2 | 0.11 | 24.20 | 20.20 | 25.25 | 2.58 | 20.70 | 25.88 | 2.64 | 22.50 | 28.13 | 2.87 |
| 14 | 9/16 | 1-3/4 | 0.15 | 33.00 | 27.00 | 33.75 | 3.44 | - | - | - | - | - | - |
| 16 | 5/8 | 2 | 0.20 | 43.12 | 36.00 | 45.00 | 4.59 | 36.00 | 45.00 | 4.59 | 38.30 | 47.88 | 4.89 |
| 18 | 3/4 | 2-1/4 | 0.25 | 54.56 | 45.00 | 56.25 | 5.74 | - | - | - | - | - | - |
| 20 | 4/5 | 2-1/2 | 0.31 | 67.32 | 54.00 | 67.50 | 6.89 | 56.70 | 70.88 | 7.23 | 60.30 | 75.38 | 7.69 |
| 22 | 7/8 | 2-3/4 | 0.37 | 81.40 | 63.90 | 79.88 | 8.15 | - | - | - | - | - | - |
| 24 | 1 | 3 | 0.44 | 96.80 | 76.50 | 95.63 | 9.76 | 81.00 | 101.25 | 10.33 | 85.50 | 106.88 | 10.91 |
| 26 | 1-1/16 | 3-1/4 | 0.52 | 113.74 | 90.00 | 112.50 | 11.48 | - | - | - | - | - | - |
| 28 | 1-1/8 | 3-1/2 | 0.60 | 131.78 | 106.00 | 132.50 | 13.52 | 106.00 | 132.50 | 13.52 | 113.00 | 141.25 | 14.41 |
| 30 | 1-1/5 | 3-3/4 | 0.69 | 151.36 | 119.00 | 148.75 | 15.18 | 119.00 | 148.75 | 15.18 | 126.00 | 157.50 | 16.07 |
| 32 | 1-1/4 | 4 | 0.78 | 172.04 | 135.00 | 168.75 | 17.22 | 135.00 | 181.00 | 18.47 | 144.00 | 181.00 | 18.47 |
| 36 | 1-7/16 | 4-1/2 | 0.99 | 217.80 | 171.00 | 213.75 | 21.81 | 171.00 | 213.75 | 21.81 | 180.00 | 225.00 | 22.96 |
| 40 | 1-9/16 | 5 | 1.22 | 268.84 | 212.00 | 265.00 | 27.04 | 212.00 | 260.00 | 26.53 | 225.00 | 260.00 | 26.53 |
| 44 | 1-3/4 | 5-1/4 | 1.48 | 325.16 | 252.00 | 315.00 | 32.14 | 252.00 | 315.00 | 32.14 | 270.00 | 337.50 | 34.44 |
| 48 | 1-7/8 | 6 | 1.76 | 386.98 | 302.00 | 377.50 | 38.52 | 302.00 | 377.50 | 38.52 | 320.00 | 400.00 | 40.82 |
| 52 | 2-1/16 | 6-1/2 | 2.07 | 454.30 | 338.00 | 422.50 | 43.11 | 360.00 | 450.00 | 45.92 | 383.00 | 478.75 | 48.85 |
| 56 | 2-1/4 | 7 | 2.40 | 526.90 | 383.00 | 478.75 | 48.85 | 405.00 | 506.25 | 51.66 | 428.00 | 535.00 | 54.89 |
| 60 | 2-3/8 | 7-1/2 | 2.75 | 604.78 | 450.00 | 562.50 | 57.40 | 450.00 | 562.50 | 57.40 | 477.00 | 596.25 | 60.84 |
| 64 | 2-1/2 | 8 | 3.13 | 688.16 | 504.00 | 630.00 | 64.29 | 504.00 | 630.00 | 64.29 | 540.00 | 675.00 | 68.88 |
| 72 | 2-7/8 | 9 | 3.96 | 870.98 | 639.00 | 798.75 | 81.51 | 639.00 | 798.75 | 81.51 | 675.00 | 843.75 | 86.10 |
| 80 | 3-5/32 | 10-1/2 | 4.89 | 1075.14 | 765.00 | 956.25 | 97.58 | 810.00 | 1012.50 | 103.32 | 855.00 | 1068.75 | 109.06 |
| 88 | 3-7/16 | 11 | 5.91 | 1301.08 | 954.00 | 1192.50 | 121.68 | 954.00 | 1192.50 | 121.66 | 1008.00 | 1260.00 | 128.57 |
| 96 | 3-13/16 | 12 | 7.04 | 1548.36 | 1125.00 | 1406.25 | 143.49 | 1120.00 | 1400.00 | 142.86 | 1188.00 | 1485.00 | 151.53 |
| 104 | 4-1/8 | 13 | 8.26 | 1817.20 | 1260.00 | 1575.00 | 160.71 | 1350.00 | 1687.00 | 172.19 | 1440.00 | 1800.00 | 183.67 |
| 112 | 4-7/16 | 14 | 9.58 | 2170.60 | 1440.00 | 1800.00 | 183.67 | 1530.00 | 1912.50 | 195.15 | 1620.00 | 2025.00 | 206.63 |
| 120 | 4-3/4 | 15 | 11 | 2419.12 | 1710.00 | 2137.00 | 218.11 | 1710.00 | 2137.50 | 218.11 | 1800.00 | 2250.00 | 229.59 |
| 128 | 5-1/5 | 16 | 12.51 | 2752.42 | 1908.00 | 2385.00 | 243.37 | 2016.00 | 2520.00 | 257.44 | 2124.00 | 2655.00 | 270.92 |
| 136 | 5-2/5 | 17 | 14.12 | 3107.28 | 2124.00 | 2655.00 | 270.92 | 2250.00 | 2812.00 | 286.99 | 2385.00 | 2981.25 | 304.21 |
| 144 | 5-4/5 | 18 | 15.84 | 3483.70 | 2385.00 | 2981.25 | 304.21 | 2520.00 | 3150.00 | 321.43 | 2700.00 | 3375.00 | 344.39 |
| 160 | 6-2/5 | 20 | 19.55 | 4301.00 | 3015.00 | 2768.75 | 384.57 | 3015.00 | 3768.75 | 384.57 | 3195.00 | 3993.75 | 407.53 |
Biz bilan qanday hamkorlik qilish mumkin?
Tez taklif qilish uchun bizga qo'ng'iroq qilishdan yoki bizga ba'zi asosiy ma'lumotlarga ega elektron pochta xabarini yuborishdan tortinmang.
Bizning joylashuvimiz
Lichuan sanoat parki, Fuchjou shahri, Jiangsi viloyati, Xitoy
Telefon raqami
+86 13225995577
shirley@fzdali.com
Issiq teglar: polyester er-xotin ortiqcha oro bermay yatch arqon, Xitoy polyester ikki ortiqcha oro bermay yatch arqon ishlab chiqaruvchilari, etkazib beruvchilar, zavod
